A Concise Introduction to Engineering Graphics (formerly titled Engineering Graphics Theory and Problems) gives students a basic understanding of how to create and read engineering drawings. The book consist of thirteen chapters that cover the basics of Engineering Graphics. The text is 142 pages in length and is followed by 40 exercise sheets. The exercise sheets both challenge the students and allow them to practice the topics covered in the text. Instructors have the choice of four different sets of exercise sheets to be bundled with this textbook. The text from the chapters are the same and the problem sets are similar. Instructors can switch the problem sets every semester to discourage students from sharing old assignments. This textbook may also be purchased without a workbook to be used as a text only.Table of Contents1. Sketching Techniques2. Hand Lettering3. Isometric Drawing4. Multiview Drawing5. Line Types6. Auxiliary Views7. Sectional Views8. Measurement and Scale9. Dimensioning10. General Tolerance11. Geometric Dimensioning and Tolerancing (GD&T)12. Working Drawings13. Threads
