Graphics for Architecture,New
Delivery time: 8-12 business days (International)
Graphics for Architecture Kevin Forseth with David Vaughan A thorough understanding of design drawing enhances the designer's ability to reason out difficult graphic constructions and to select or create appropriate means for depicting buildings and environments. This fully illustrated guide presents the most effective methods for mechanically constructing architectural plans, elevations, sections, paralines, perspectives, and shadows. All methods are described in basic principles of perspective geometry. Throughout the volume many pictorial drawings illuminate the connection between stepbystep procedures for constructing design drawings and the abstract concepts underlying orthographic, oblique, and perspective projections. For formulating graphics workbook problems around paraline construction the guide includes a notation system for describing an unlimited range of paralineoblique drawings. A shortcut method for casting shadows in plan and elevation is useful for modeling shadows in architectural site plans and for obtaining fast design results. In addition there are eight different stepbystep procedures for setting up and constructing one and twopoint perspective. Commonmethod perspectives are presented in the context of a draftingboard surface, and perspectives without plan are discussed as interiors, exteriors, and sections. Combining carefully organized learning sequences with the quick reference qualities of a handbook, this volume is an excellent reference source for the architectural office or studio as well as an easytofollow manual for students.
