How To Use The Snapon Modis: (Includes Features And How To Use Together With Other Tools),Used
Delivery time: 8-12 business days (International)
How to Use The SnapOn MODIS With the ever increasing electronic content in todays vehicles, the scan tool has become the tool of choice to look into the ECM or module functions. The scanner is the only window into what the different modules are doing. One things to use an oscilloscope or GMM, but to know what the computer is actually interpreting, your only choice is this piece of equipment. This book is different than other book on the MODIS. This book actually teaches you how to use the equipment and interpret the PID datastream. This book also borrows from some of our other publications, but geared towards the Modis. We also expose the use of other diagnostic equipment and how to use them together. In todays automotive repair shop the technician has to be able to use the equipment and draw relational characteristics between the signal. It is from these relations that the tech arrives to the true repair. Its not just using the Modis. Its using the Modis and see if the scope and multimeter readings also support the repair conclusion. SnapOn has over the years developed into a leader in diagnostic equipment. With that in mind, lets learn to use the MODIS to its fullest and become a profitable, top technician. Remember, learning to use your equipment will also teach you a great deal of diagnostics. Table of Contents Basic Features Modular Diagnostic System BUTTON ARRANGEMENT DESCRIPTION UPDATING THE MODIS SCANNER GRAPHING THE PIDs SAVING YOUR SCREEN SNAPSHOTS AND BULDING YOUR OWN LIBRARY A WORD ABOUT THE BATTERY CARE and MAINTENANCE GENERAL SCANNER FUNCTION & PID ANALYSIS THEORY OF OPERATION BEHIND THE DIFFERENT PARAMETERS (PIDs) OBD I and OBD II, and general PID analysis FUEL DELIVERY FAULT DETECTION TEST 1 Misfire detection strategy (EGR, ignition and mechanical misfires) TEST 2 A/F RATIO FAULTS TEST 3 CLOGGED EXHAUST The MODIS Troubleshooter GRAPHING THE PIDs THE SNAPSHOT FEATURE OBD2 Operability Using the MODIS in conjunction with other types of equipment (TestLight, AmpProbes, GMM, DVOM, Oscilloscope)
