THE LATEST SPICE SIMULATION AND DESIGN TOOLS FOR CREATING STATEOFTHEART SWITCHING POWER SUPPLIES Fully updated to incorporate new SPICE features and capabilities, this practical guide explains, step by step, how to simulate, test, and improve switchmode power supply designs. Detailed formulas with founding equations are included. Based on the author's continued research and indepth, handson work in the field, this revised resource offers a collection of the latest SPICE solutions to the most difficult problem facing power supply designers: creating smaller, more heatefficient power supplies in shorter design cycles.NEW to this edition:Complete analysis of rms currents for the three basic cells in CCM and DCM PWM switch at work in the smallsignal analysis of the DCM boost and the QR flyback OTAbased compensators Complete transistorlevel TL431 model Smallsignal analysis of the borderlineoperated boost PFC circuit operated in voltage or current mode Allover power phenomena in QR or fixedfrequency discontinuous/continuous flyback converters Smallsignal model of a QR flyback converter Smallsignal model of the active clamp forward converter operated in voltagemode control Electronic contentdesign templates and examples available onlineSwitchMode Power Supplies: SPICE Simulations and Practical Designs, Second Edition, covers:Smallsignal modeling * Feedback and ciontrol loops * Basic blocks and generic switched models * Nonisolated converters * Offline converters * Flyback converters * Forward converters * Power factor correction
