Visualization & Engineering Design Graphics with Augmented Reality,Used
Delivery time: 8-12 business days (International)
Visualization and Engineering Design Graphics with Augmented Reality is designed as a learning tool to help the aspiring engineer learn the language of engineering graphics. In this regard, this book is hardly unique, as there have been literally hundreds of books published in the past that had a similar goal. The main challenge faced by engineering graphics books comes from the difficulty of representing and describing three dimensional information on paper, which is a consequence of the two dimensional nature of printed materials.What makes this book invaluable is the use of Augmented Reality, a technology that will allow you to escape the limitations of traditional materials enabling you, the student, to truly visualize the objects being described in full 3D. To take full advantage of this book, you will need a computer with the software provided and a web camera*. Many parts of the book are linked to specific augmented reality content through a series of black and white marks that have been seamlessly integrated throughout the pages. In order to experience the content, your camera must be pointed at these marks. The main mark, available at the beginning of the book, is used to interact with the augmented reality models, which will be rendered in real time in your computer screen.* If you do not have a webcam connected to your computer, SolidWorks files of the models used throughout the book are included on the CD. In addition, STL files have been provided so the models can be opened using your solid modeling CAD package of choice or printed on a 3D printer.Table of ContentsIntroduction Sketching and Lettering Orthographic Projection Pictorials Sectional Views Auxiliary Views Dimensioning Tolerances Threaded Fasteners Working DrawingsAppendix
